Zxtech 5MP AHD CCTV System - 1 x Analog Camera Outdoor Optical Zoom Enhanced Night Vision Sony Starvis | AF1G4Z
Zxtech
SKU: AF1G4Z
Unbeatable value for money. Superb 5 Megapixel resolution. 2.8-12mm Varifocal lens for optical zoom. Stunning 60-metre night vision. Easily DIY the complete system in minutes. Instantly remote view and receive an alert with free app. Turn on the AI with magical face and body detection. Waterproof and vandal-proof. Hybrid fusion mode for both analog and IP cameras. Includes with all accessories.
Product Overview
The Best value for money Super HD 5MP CCTV Kits provides you with a reliable surveillance system in superior quality. Breathtaking 60M LED night vision captures every detail of the longest garden or driveway in the night. Optically zoom in/out with the flexible varifocal lens for further or wider sight. 5 Megapixel resolution is mind-blowingly 2.5x sharper than 1080p. You can DIY the whole system in minutes even faster than a CCTV specialist. Enter the AI era with magical face recognition and body detection. With 1 quick scan of the QR code, you can instantly remotely access your system anywhere anytime with our free app including smart push notification. Every accessory you need is included in the package. Achieve immediate live streaming by simply connect the cameras to the recorder. The compacted Metalic waterproof and vandal-proof bullet casing is a perfect solution for every family. The system is expandable up to 4 channel so you can add 3 additional cameras. The recorder is hybrid, so you can even connect IP cameras.
Highlights
- Unbeatable value for money
- Superb 5 Megapixel resolution
- 2.8-12mm Varifocal lens for optical zoom
- Stunning 60-metre night vision
- Easily DIY the complete system in minutes
- Instantly remote view and receive an alert with free app
- Turn on the AI with magical face and body detection
- Waterproof and vandal-proof
- Hybrid fusion mode for both analog and IP cameras
- Includes with all accessories
What's in the Box
- 1 x Zxtech Premix Grey CCTV Camera
- 1 x 4CH Onyx 4K Hybrid Video Recorder
- 1 x 10M cable and 1 x 2M Cable
- power adaptors
- Optional HDD and Monitor
Camera Specs
| Image Sensor | 1/2.8'' SONY Starvis Back-illuminated CMOS sensor |
| Image Resolution | 5M:2592*1944 4M:2560*1440 2M:1920*1080 |
| Electronic Shutter | AUTO |
| TV System | PAL/NTSC |
| Scanning System | Progressive Scan |
| Focus Length | 2.8-12mm |
| Focus Control | Manual |
| Lens Type | Manual |
| IR Cut Filter | YES |
| Infrared LED | 42µ x 6PCS |
| Infrared Distance | 60M |
| IR Status | AGC Auto Control |
| Starlight | / |
| Day/Night | YES |
| OSD Menu Language | YES |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| Noise Reduction | DNR |
| WDR | DWDR |
| UTC | YES |
| Housing | IP66 |
| Bracket | YES |
| Operation Temperature | -10℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%,900mA |
| Dimension | 290(W) x 92(H) x 80(D)mm |
| Weight | 1.4Kg |
DVR Specs
| Main Processor: | HI3520DV400 |
| Operating System: | Embedded LINUX |
| Video Input: | Normal Mode: Default: 4*(AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H) + 2*network(MAX 5MP) Analog+Network: 2*Analog(AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+ 7*network(MAX 5MP) Lite Mode: Default: 4*(TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+2*network(MAX 5MP) Analog+Network: 2*Analog(TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+7*network(MAX 5MP) Network: 16*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth <48M) |
| Input: | 4CH |
| Signal Type: | Analog/AHD/TVI2.0/TVI3.0/CVI/Network |
| Output: | 1HD, 1VGA, 1CVBS |
| Alarm Input: | 4CH |
| Alarm Output: | 1CH |
| Audio Input: | 2 CH , RCA |
| Audio Output: | 1CH |
| Motion Detection: | 4 Channel(max 16 Channel in pure network mode) |
| Trigger Events: | Recording, Email, Screen tips, Buzzer, Push notifications(motion detection) |
| Email Alarm: | Image to The Designated E-mail |
| Face Comparison: | 1 channel video stream face Comparison(1 face databases with 10 face images) |
| Interface: | RS485 |
| Protocol: | Pelco-D, Pelco-P |
| VGA: | 1920 x 1080P/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz,1024 x 768/60Hz |
| HD Output: | 1920 x 1080P/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz,1024 x 768/60Hz |
| Display Split: | 16 Channel/ 9 Channel/ 4 Channel / 1 Channel |
| Privacy Masking: | 3 Rectangular Zones (Each camera) |
| OSD: | Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Video Compression: | H.265/H.265+/H.264/H.264+ |
| Audio Compression: | G.711u/G.711a |
| Resolution: | 5MP(2592x1944), 8MP_LITE(1920x2160), 5MP_HALF(1296x1944), 4MP(2560x1440), 4MP_HALF(1280x1440), 3MP(2048x1536), 3MP_Lite(1024x1536), 1080P(1920x1080), 720P(1280x720), 960H(P:960x576/N:960x480) |
| Record Rate | Normal Mode: Analog: PAL:8MP_LITE(1920x2160 4*8fps), 5MP(2592×1944 4*6fps), 5MP_HALF(1296x1944 4*10fps),4MP(2560x1440 4*8fps),4MP_HALF(1280x1440 4*15fps),3MP(2048x1536 4*9fps),3MP_Lite(1024x1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280x720 4*25fps), 960H(960x576 4*25fps) NTSC:8MP_LITE(1920x2160 4*8fps), 5MP(2592x1944 4*6fps), 5MP_HALF(1296x1944 4*10fps), 4MP(2560x1440 4*8fps), 4MP_HALF(1280x1440 4*15fps),3MP(2048x1536 4*9fps), 3MP_Lite(1024x1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280x720 4*25fps), 960H(960x480 4*25fps) Lite Mode: PAL:5MP_Lite(1296x1944 4*10fps), 4MP_Lite(1280x1440 4*15fps),3MP_Lite(1024x1536 4*18fps), 1080N(960x1080 4*25fps), 720P(1280x720 4*25fps), 960H(960x480 4*25fps) NTSC: 5MP_Lite(1296×1944 4*10fps),4MP_Lite(1280x1440 4*15fps),3MP_Lite(1024x1536 4*18fps),1080N(960x1080 4*25fps),720P(1280x720 4*25fps), 960H(960x480 4*30fps) Pure IP(H.265): PAL: 5MP@8x25fps, 4MP@12x25fps, 3MP@12x25fps, 1080P@16x25fps, 960P@16x25fps, 720P@16x25fps, D1@16x25fps NTSC: 5MP@8x30fps,4MP@12x30fps,3MP@12x30fps,1080P@16x30fps, 960P@16x30fps, 720P@16x30fps, D1@16x30fps |
| Record Mode: | Manual\Timer\Motion Detection\AI Alarm\Alarm Input |
| Decode Capability: | 2CH 1080P@30fps |
| Sync Playback: | Pure Analog: 4CH 5M@6fps, 4CH 8M_Lite@8fps, 4CH 4M@8fps, 4CH 3M@9fps, 4CH 1080p@15fps, 4CH 1080N@25fps Mix Mode: 1CH 5M@30fps, 1CH 4M@30fps, 1CH 3M@30fps, 2CH 1080P@30fps, 4CH 1080p@15fps Pure IPC: 1CH 5MP@30fps, 1CH 4MP@30fps, 1CH 3M@30fps, 4CH 1080P@15fps, 2CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps |
| Remote Playback: | 4 Channel / 1Channel |
| Search Mode: | ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions: | Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen |
| Smart Phone Playback: | 4 Channel |
| Backup Mode: | USB Device(with fomat FAT 32 )/Network/FTP |
| Network Interface: | 1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions: | TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
| DDNS: | Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE |
| Web Browser: | IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) |
| CMS Software: | Support Windows 7/ Windows 8/Windows 10 |
| Extra Stream: | CIF/D1(1-30fps) |
| Smart Phone: | iPhone, ipad, Android ,Android pad Hard Disk Driver Interface Type 1 SATA Interface |
| Capacity: | 1 SATA Hard Disk (2.5"/3.5" SATA, Up to 6TB |
| Language: | Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek, Japanese |
| UTC Control: | YES |
| USB Interface: | 2 USB 2.0 Interfaces |
| Power consumption: | DC 12V/2A <6W (Without Hard Disk) |
| Dimension (WxDxH): | 260*215*43(m) |
