Zxtech 3x Cameras 4K-Lite CCTV Kit - AHD Varifocal 30M Night Vision 4CH DVR | AX3E4Z

Zxtech SKU: AX3E4Z

Zxtech 3x Cameras 4K-Lite CCTV Kit - AHD Varifocal 30M Night Vision 4CH DVR | AX3E4Z

Zxtech SKU: AX3E4Z
Storage
Regular price £168.73
/
Tax included. Shipping calculated at checkout.
  • UK next business day delivery
  • 30 days hassle free returns
  • UK VAT invoices included
  • Secure payments
Zxtech 3x 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Cameras 4CH DVR CCTV Kit | AX3E4Z
Zxtech 3x 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Cameras 4CH DVR CCTV Kit | AX3E4Z
Zxtech 3x Cameras 4K-Lite CCTV Kit - AHD Varifocal 30M Night Vision 4CH DVR | AX3E4Z
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 8MP 4K UHD 30M Night Vision 2.8-12mm Varifocal Dome Camera
Zxtech 4CH 4K 5MP Digital Video Recorder DVR
Zxtech 4CH 4K 5MP Digital Video Recorder DVR
Zxtech 4CH 4K 5MP Digital Video Recorder DVR
Zxtech 4CH 4K 5MP Digital Video Recorder DVR
Zxtech 4CH 4K 5MP Digital Video Recorder DVR

High-quality 4-in-1 4K-Lite resolution camera. From narrow to wide angle with 2.8-12 mm lens. Improved 30-metre night vision. Quick set up the complete system in minutes. Remote view and receive alerts with free app. Support face recognition and face comparision AI functions. Waterproof and vandal-proof. Hybrid fusion mode for both analog and IP cameras. All accessories included

Product Overview

Compact eyeball dome security camera giving you from narrow to wide angle with 2.8-12mm varifocal lens, manual zoom and focus. The camera has universal compatibility with 4-in-1 mode and provides Ultra HD quality in 4K-Lite resolution. Quick set up in few minutes and remote view anytime and anywhere. The system includes 4K-Lite CCTV Digital Video Recorder for real-time 8MP recording. Included recorder supports motion, face and body detection. The camera has extended night vision allows you to see clear in the dark. You will be able to fit the camera outside or inside your home. High- performance 8MP sensor for quality image, anti-vandal and waterproof IP66 rated metal case as a finish. This DVR is also a hybrid recorder enable to connect analog and IP cameras.

Highlights

  • Real value for money
  • High-quality 4-in-1 4K-Lite resolution camera
  • From narrow to wide angle with 2.8-12 mm lens
  • Improved 30-metre night vision
  • Quick set up the complete system in minutes
  • Remote view and receive alerts with free app
  • Support face recognition and face comparision AI functions
  • Waterproof and vandal-proof
  • Hybrid fusion mode for both analog and IP cameras
  • All accessories included

What's in the Box

  • 3 x Zxtech Halo Plus Grey CCTV Camera
  • 1 x 4CH Onyx 4K-Lite Hybrid Video Recorder
  • 2 x 10M cable, 1 x 20M cable and 1 x 2M Cable
  • power adaptors, power splitter
  • Optional HDD and Monitor
Zxtech 3x 8MP 4K-Lite UHD 30M Night Vision 2.8-12mm Varifocal Dome Cameras 4CH DVR CCTV Kit | AX3E4Z

Camera Specs

Video Output Mode AHD/TVI:8M@15fps,5M@20fps/12.5fps, 4M/2M@30fps/25fps;CVI: 8M@15fps/12.5fps,4M/2M@30fps/25fps
Image Sensor 1/2.5" CMOS sensor
Image Resolution 8M:3840*2160 5M:2592*19444M:2560*1440 2M:1920*1080
Electronic Shutter AUTO
TV System PAL/NTSC
Scanning System Progressive Scan
Focus Length Board Lens 2.8-12mm
Focus Control Manual
Lens Type Manual
IR Cut Filter YES
Infrared LED 14µ x 24PCS
Infrared Distance 30M
IR Status AGC Auto Control
Day/Night YES
OSD Menu Language YES
White Balance AUTO / MANUAL
Gain Control AUTO
Noise Reduction 3DNR
WDR DWDR
UTC YES
Housing IP66
Power Source DC12V, 750mA
Dimension 119 x 98(H) mm
Weight 800g

DVR Specs

Main Processor: HI3520DV400
Operating System: Embedded LINUX
Video Input: Normal Mode: Default: 4*(AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H) + 2*network(MAX 5MP)
Analog+Network: 2*Analog(AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+ 7*network(MAX 5MP)
Lite Mode:
Default: 4*(TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+2*network(MAX 5MP)
Analog+Network: 2*Analog(TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+7*network(MAX 5MP)
Network: 16*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth <48M)
Input: 4CH
Signal Type: Analog/AHD/TVI2.0/TVI3.0/CVI/Network
Output: 1HD, 1VGA, 1CVBS
Alarm Input: 4CH
Alarm Output: 1CH
Audio Input: 2 CH , RCA
Audio Output: 1CH
Motion Detection: 4 Channel(max 16 Channel in pure network mode)
Trigger Events: Recording, Email, Screen tips, Buzzer, Push notifications(motion detection)
Email Alarm: Image to The Designated E-mail
Face Comparison: 1 channel video stream face Comparison(1 face databases with 10 face images)
Interface: RS485
Protocol: Pelco-D, Pelco-P
VGA: 1920 x 1080P/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz,1024 x 768/60Hz
HD Output: 1920 x 1080P/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz,1024 x 768/60Hz
Display Split: 16 Channel/ 9 Channel/ 4 Channel / 1 Channel
Privacy Masking: 3 Rectangular Zones (Each camera)
OSD: Camera title, Time, Video loss, Alarm, Motion detection, Recording
Video Compression: H.265/H.265+/H.264/H.264+
Audio Compression: G.711u/G.711a
Resolution: 5MP(2592x1944), 8MP_LITE(1920x2160), 5MP_HALF(1296x1944), 4MP(2560x1440), 4MP_HALF(1280x1440), 3MP(2048x1536), 3MP_Lite(1024x1536), 1080P(1920x1080), 720P(1280x720), 960H(P:960x576/N:960x480)
Record Rate Normal Mode: Analog:
PAL:8MP_LITE(1920x2160 4*8fps), 5MP(2592×1944 4*6fps), 5MP_HALF(1296x1944 4*10fps),4MP(2560x1440 4*8fps),4MP_HALF(1280x1440 4*15fps),3MP(2048x1536 4*9fps),3MP_Lite(1024x1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280x720 4*25fps), 960H(960x576 4*25fps)
NTSC:8MP_LITE(1920x2160 4*8fps), 5MP(2592x1944 4*6fps), 5MP_HALF(1296x1944 4*10fps), 4MP(2560x1440 4*8fps), 4MP_HALF(1280x1440 4*15fps),3MP(2048x1536 4*9fps), 3MP_Lite(1024x1536 4*18fps), 1080P(1920x1080 4*15fps),720P(1280x720 4*25fps), 960H(960x480 4*25fps)
Lite Mode:
PAL:5MP_Lite(1296x1944 4*10fps), 4MP_Lite(1280x1440 4*15fps),3MP_Lite(1024x1536 4*18fps), 1080N(960x1080 4*25fps), 720P(1280x720 4*25fps), 960H(960x480 4*25fps)
NTSC: 5MP_Lite(1296×1944 4*10fps),4MP_Lite(1280x1440 4*15fps),3MP_Lite(1024x1536 4*18fps),1080N(960x1080 4*25fps),720P(1280x720 4*25fps), 960H(960x480 4*30fps)
Pure IP(H.265):
PAL: 5MP@8x25fps, 4MP@12x25fps, 3MP@12x25fps, 1080P@16x25fps, 960P@16x25fps, 720P@16x25fps, D1@16x25fps
NTSC: 5MP@8x30fps,4MP@12x30fps,3MP@12x30fps,1080P@16x30fps, 960P@16x30fps, 720P@16x30fps, D1@16x30fps
Record Mode: Manual\Timer\Motion Detection\AI Alarm\Alarm Input
Decode Capability: 2CH 1080P@30fps
Sync Playback: Pure Analog: 4CH 5M@6fps, 4CH 8M_Lite@8fps, 4CH 4M@8fps, 4CH 3M@9fps, 4CH 1080p@15fps, 4CH 1080N@25fps
Mix Mode: 1CH 5M@30fps, 1CH 4M@30fps, 1CH 3M@30fps, 2CH 1080P@30fps, 4CH 1080p@15fps
Pure IPC: 1CH 5MP@30fps, 1CH 4MP@30fps, 1CH 3M@30fps, 4CH 1080P@15fps, 2CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps
Remote Playback: 4 Channel / 1Channel
Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection
Playback Functions: Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen
Smart Phone Playback: 4 Channel
Backup Mode: USB Device(with fomat FAT 32 )/Network/FTP
Network Interface: 1 RJ45 10M/100M Adaptive Ethernet Interface
Network Functions: TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNS: Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE
Web Browser: IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS Software: Support Windows 7/ Windows 8/Windows 10
Extra Stream: CIF/D1(1-30fps)
Smart Phone: iPhone, ipad, Android ,Android pad Hard Disk Driver Interface Type 1 SATA Interface
Capacity: 1 SATA Hard Disk (2.5"/3.5" SATA, Up to 6TB
Language: Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek, Japanese
UTC Control: YES
USB Interface: 2 USB 2.0 Interfaces
Power consumption: DC 12V/2A <6W (Without Hard Disk)
Dimension (WxDxH): 260*215*43(m)
