Zxtech 8x Cameras 4K-Lite CCTV Kit - AHD Night Vision 16CH DVR | AX8B16X
Zxtech
SKU: AX8B16X
High-quality 4-in-1 4K-Lite resolution camera. Super wide angle lenses. Improved 20-metre night vision. Quick set up the complete system in minutes. Remote view and receive alerts with free app. Support face recognition and face comparision AI functions. Waterproof and vandal-proof. Hybrid fusion mode for both analog and IP cameras. All accessories included
Product Overview
Long-lasting quality solution against crime is fully equipped with plenty of features like guarantee quality 4K-Lite Analog AHD CCTV in ultra-high definition. 4 times sharper than traditional 1080p. Zxtech introducing 4K-Lite Plug and Play system ideal from home or business surveillance. Super compact metal waterproof camera included with 4K-Lite CCTV DVR gives you super wide-angle in 3.6mm lens and high-performance CMOS sensor. The camera has improved night vision suitable for indoor or outdoor. Quick set up in few minutes hassle-free and remotely view anytime and anywhere, enable motion detection and receive mobile alerts. The camera has an OSD joystick for switching between 4 modes. Wanted outdoor security camera water-resistant and vandal-proof solid case. This kit includes 4K-Lite real-time CCTV DVR featuring motion, face and body detection.
Highlights
- Real value for money
- High-quality 4-in-1 4K-Lite resolution camera
- Super wide angle lenses
- Improved 20-metre night vision
- Quick set up the complete system in minutes
- Remote view and receive alerts with free app
- Support face recognition and face comparision AI functions
- Waterproof and vandal-proof
- Hybrid fusion mode for both analog and IP cameras
- All accessories included
What's in the Box
- 8 x Zxtech Halo Grey CCTV Camera
- 1 x 16CH Onyx 4K-Lite Hybrid Video Recorder
- 4 x 10M cable, 4 x 20M cable and 1 x 2M Cable
- power adaptors
- Optional HDD
Camera Specs
| Video Output Mode | AHD: 8M@15fps, 5M@20fps/12.5fps, 4M/2M@30fps/25fps; CVI:8M@15fps/12.5fps,4M/2M@30fps/25fps; TVI: 8M@15fps/12.5fps, 5M@20fps/12.5fps, 4M/2M@30fps/25fps |
| Image Sensor | 1/2.5" CMOS sensor |
| Image Resolution | 8M:3840*2160 5M:2592*19444M:2560*1440 2M:1920*1080 |
| Electronic Shutter | AUTO |
| TV System | PAL/NTSC |
| Scanning System | Progressive Scan |
| Focus Length | Board Lens 3.6mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
| IR Cut Filter | YES |
| Infrared LED | 14µ x 18PCS |
| Infrared Distance | 20M |
| IR Status | AGC Auto Control |
| Day/Night | YES |
| OSD Menu Language | YES |
| White Balance | AUTO / MANUAL |
| Gain Control | AUTO |
| Noise Reduction | 3DNR |
| WDR | DWDR |
| UTC | YES |
| Housing | IP66 |
| Power Source | DC12V, 550mA |
| Dimension | 93 x 74(H) mm |
| Weight | 400g |
DVR Specs
| Input | Normal Mode: Default: 16*AHD/TVI/CVI:8M; TVI/AHD: 5M; AHD/TVI/CVI: 4M; AHD/TVI: 3M; AHD/TVI/CVI: 1080P/720P; Analog: 960H)+8*network(Max 8MP) Analog+Network: 14*Analog(8MP)+11*network(Max 8MP), 12*Analog(8MP)+13*network(Max 8MP), 10*Analog(8MP)+15*network(Max 8MP), 8*Analog(8MP)+17*network(Max 8MP), 6*Analog(8MP)+19*network(Max 8MP), 4*Analog(8MP)+21*network(Max 8MP), 2*Analog(8MP)+23*network(Max 8MP) Lite Mode: Analog: 16*AHD/TVI/CVI: 1080P/720P; Analog: 960H) Analog+Network: 14*Analog(5MP)+11*network(Max 8MP), 12*Analog(5MP)+13*network(Max 8MP), 10*Analog(5MP)+15*network(Max 8MP), 8*Analog(5MP)+17*network(Max 8MP), 6*Analog(5MP)+19*network(Max 8MP), 4*Analog(5MP)+21*network(Max 8MP), 2*Analog(5MP)+23*network(Max 8MP) Network: 32*network(Max 8MP)(Total incoming bandwidth ≤160M) |
| Input | 16CH BNC |
| Signal Type | Analog/AHD/CVI/TVI 2.0/TVI 3.0/Network |
| Output | 1HD,1 VGA, 1 CVBS |
| Audio | PAL/NTSC |
| Input | 2 Channel, RCA |
| Two-way Audio | NO |
| Output | 1 Channel, RCA |
| Alarm | Manual |
| Sensor Input | No |
| Output | No |
| Motion Detection | 16 Channel(max 32 Channel in pure network mode) |
| Trigger Events | Recording, Email, Screen tips, Buzzer, Push notifications(motion detection) |
| Email Alarm | Send Image to The Designated E-mail |
| AI Function | YES |
| Face Comparison | 4 channel video stream face Comparison(1 face databases with 10 face images) |
| PTZ | |
| Interface | RS485 |
| Protocol | Pelco-D, Pelco-P |
| Baud Rate | 110~921600 |
| Address | 0~255 |
| Display | |
| VGA | Resolution: 1920 x 1080P/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz,1024 x 768 /60Hz |
| HD Output | Resolution: 3840x2160/30Hz, 2560x1440/30Hz, 1920x1080P/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Display Split | 36 Channel/25 Channel/16 Channel/9 Channel/8 Channel/4 Channel / 1Channel |
| Privacy Masking | 3 Rectangular Zones (Each camera) |
| OSD | Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Recording | |
| Video Compression | H.265/H.265+/H.264/H.264+ |
| Audio Compression | G.711u/G.711a |
| Resolution | 5MP(2592x1944), 8MP_LITE(1920x2160), 5MP_HALF(1296x1944), 4MP(2560x1440), 4MP_HALF(1280x1440), 3MP(2048x1536), 3MP_Lite(1024x1536 4*18fps), 1080P(1920x1080), 720P(1280x720), 960H(P:960x576/N: 960x480) |
| Video Quality | worst/worse/ordinary/well/best |
| Record Rate | Normal Mode: Analog:PAL: 8MP_LITE(1920x2160 16*8fps), 5MP(2592x1944 16*6fps), 5MP_LITE(1296x1944 16*10fps), 4MP(2560x1440 16*8fps), 4MP_LITE(1280x1440 16*15fps), 3MP(2048x1536 16*9fps), 3MP_Lite(1024x1536 16*18fps), 1080P(1920x1080 16*15fps), 720P(1280x720 16*25fps), 960H(960x576 16*25fps) NTSC: 8MP_LITE(1920x2160 16*8fps), 5MP(2592x1944 16*6fps), 5MP_LITE(1296x1944 16*10fps), 4MP(2560x1440 16*8fps), 4MP_LITE(1280x1440 16*15fps), 3MP(2048x1536 16*9fps), 3MP_Lite(1024x1536 16*18fps), 1080P(1920x1080 16*15fps), 720P(1280x720 16*30fps), 960H(960x480 16*30fps) Lite Mode: PAL:5MP_Lite(1296x1944 16*10fps), 4MP_Lite(1280x1440 16*15fps), 3MP_Lite(1024x1536 16*18fps), 1080N(960x1080 16*25fps), 720P(1280x720 16*25fps), 960H(960x480 16*25fps) NTSC: 5MP_Lite(1296x1944 16*10fps), 4MP_Lite(1280x1440 16*15fps), 3MP_Lite(1024x1536 16*18fps), 1080N(960x1080 16*25fps), 720P(1280x720 16*25fps), 960H(960x480 4*30fps) Pure IP(H.265): PAL: 4k@17x25fps, 5MP@26x25fps, 4MP@32x25fps, 3MP@32x25fps, 1080P@32x25fps, 960P@32x25fps, 720P@32x25fps, D1@32x25fpsNTSC: 4k@17x30fps,5MP@26x30fps,4MP@32x30fps,3MP@32x30fps,1080P@32x30fps, 960P@32x30fps, 720P@32x30fps, D1@32x30fps |
| Record Mode | Manual\Timer\Motion Detection\AI Alarm\Alarm Input |
| Playback & Backup | |
| Decode Capability | 9CH 720P@30fps |
| Sync Playback | Pure Analog: 16CH 8MP_LITE@8fps, 16CH 5M@6fps,16CH 5MP_LITE@10fps, 16CH 4M@8fps, 16CH 4MP_LITE@15fps, 16CH 3M@9fps, 16CH 1080p@15fps, 16CH 1080N@25fps Mix Mode: 1CH 4K@30fps, 2CH 5M@30fps, 2CH 4M@30fps, 3CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps Pure IPC: 2CH 4K@30fps, 4CH 5M@30fps, 4CH 4M@30fps, 5CH 3M@30fps, 9CH 1080P@30fps, 9CH 960P@30fps, 9CH 720P@30fps |
| Remote Playback | 4 Channel / 1 Channel |
| Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions | Play, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full screen |
| Smart Phone Playback | 4 Channel |
| Backup Mode | USB Device(with fomat FAT 32 )/Network/FTP |
| Network | |
| Interface | 1 RJ45 10M/100/1000M Adaptive Ethernet Interface |
| Network Functions | TCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP |
| DDNS | Dyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE |
| Web Browser | IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) |
| CMS Software | Support Windows 7/ Windows 8/Windows 10 |
| Extra Stream | CIF/D1(1-30fps) |
| Smart Phone | iPhone, ipad, Android ,Android pad |
| Hard Disk Driver | |
| Interface Type | 1 SATA Interface |
| Capacity | 1 SATA Hard Disk (2.5"/3.5" SATA, Up to 8TB) |
| General | |
| Language | Simplified Chinese,Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bulgarian, German, French, Portuguese,Turkish, Spanish, Italian, Hungarian, Romanian, Korean, Dutch, Greek, Vietnamese, Japanese |
| UTC Control | YES |
| USB Interface | 2 USB 2.0 Interfaces |
| Power consumption | DC 12V/2A ≤10W (Without Hard Disk) |
| Working Environment | -10~55℃/10~90% |
| Dimension (W×D×H) | 260*215*43(mm) |
| Weight | 2.0kg (Without HDD) |
