Zxtech Wireless All-in-One inbuilt-screen CCTV Kits with 4x Super HD Wi-Fi Camera

Special Price £230.01 Regular Price £292.98
Out of stock
Stunning 12" LCD display integrated NVR. Magical face and body detection. All new wireless camera with industry-leading HD Sensor. Instantly remote view and receive alerts with free app. Powerful wireless reception reaches 300 Metres*. Can extend with breathtaking 4K 8MP wireless camera. 30-metre Incredible night vision. High grade waterproof and vandal-proof. Allows additional SD Card and Audio module. An absolute all-in-one solution.

Product Overview

All-in-one CCTV solution with Stunning 12" LCD display integrated smart NVR and all-new wireless camera with industry-leading HD Sensor. Experience the future with magical face and body detection. Powerfull 300-metre wireless range is made for any type of needs. Powerful NVR can extend with breathtaking 4K 8MP wireless camera. Crispy clear images in the darkest night with amazing 30M night vision. High grade waterproof and vandal-proof camera body are made for toughest weather. Connect with your phone with the free app to receive remote live streaming and motion alert. Enable camera recording and backup with additional SD Card. Turn on voice recording with audio module. This is an absolutely cutting edge wireless system.


  • Stunning 12" LCD display integrated NVR
  • Magical face and body detection
  • All new wireless camera with industry leading Super HD 5MP Sensor
  • Instantly remote view and receive alerts with free app
  • Powerful wireless receiption reaches 300 Metres*
  • Can extend with breathtaking 4K 8MP wireless camera
  • 30-metre Incredible night vision
  • High grade waterproof and vandal-proof
  • Allows addiotnal SD Card and Audio module
  • An absolute all-in-one solution

What's in the Box

  • 4 x Zxtech 5MP CloudMini Wifi Wireless CCTV Camera
  • 1 x 4CH Ultra Mini Pro Network Video Recorder
  • Optional HDD

Tech Specs

Zxtech CloudMini Wifi Wireless IP Camera

  • Image Sensor: 1/2.5" High-resolution CMOS Sensor
  • Resolution: 5MP
  • Effective Pixels: 2608(H)*1952(V)
  • Compression: H.264/H.264+/H.265/H.265+/JPEG/AVI/MJPEG
  • TV System: PAL/NTSC
  • Electronic Shutter Time Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec
  • S/N Ratio: ≥52dB
  • Scanning System: Progressive
  • Video Output: Network
  • Focus Length: Board Lens 2.8mm/F2.0
  • Focus Control: Fixed
  • Lens Type: Fixed
  • Pixels: 5MP
  • Infrared LED: 42µx 2PCS
  • Infrared Distance: 30M
  • IR Status: Auto
  • IR Power On: Auto
  • Ethernet: RJ-45 (10/100Base-T)
  • ONVIF: Support ONVIF 2.4
  • P2P: YES, Support QR Code
  • Main Stream 1: 2592*1944@20fp 2560*1920@20fp; Main Stream 2: 2560*1440@30fp
  • Antena: 3dbi ; Wi-Fi: Wi-Fi(IEEE802.11b/g/n),2.4Ghz ; WIFI Range: No obstacles 300m Max.
  • Day/Night: Color/ B&W (IR-CUT )
  • Audio: Support
  • Image Config: Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control)
  • Corridor Pattern, Defog Mode, BLC, WDR, Motion Detection: Support; Privacy  Masking 3 Rectangular Zone
  • SD Card Slot: support  256G Micro SD With External SD Card Slot
  • Housing: Metal, IP67
  • Anti-cut Bracket: Anti-Cut 3-Axis
  • Weight: 770g

Recorder Specs


  • Main Processor: ARM Cortex A7 Quad-core Processor
  • Operating System: Embedded LINUX
  • Video Input: 4CH (3072x2592, 2048x1536, 1920x1080, 1280x960, 1280x720, etc)
  • Video Output: 1 VGA, 1 HD
  • Audio Input:
  • Audio Output: 1 Port RCA(Linear)
  • Audio Compression Standard: G711u, G711a, G726
  • Sensor Input: No
  • Output: No
  • Motion Detection: 4 Channel, MD Zones: 396 (22 x18)
  • Trigger Events: Recording, Email, FTP, Snapshot, Buzzer and Screen Tips


  • Monitor: Support 12 inch monitor built-in
  • Resolution: 8MP(3072x2592), 5MP(2592x1944), 4MP(2688x1520), 3MP(2048x1536), 1080P(1920x1080), 960P(1280x960), 720P(1280x720), D1 (720x576/720x480)
  • Record Rate: PAL: 8MP@4x15fp, 5MP@4x25fp,4MP@4x25fp,3MP@4x25fp,1080P@4x25fp, 960P@4x25fp,720P@4x25fp, D1@4x25fp NTSC: 8MP@4x15fp, 5MP@4x30fp, 4MP@4x30fp, 3MP@4x30fp, 1080P@4x30fp, 960P@4x30fp, 720P@4x30fp, D1@4x30fp
  • Record Mode: Manual/ Timer/ Motion Detection

Playback & Backup

  • Local Sync Playback: 1CH 8MP@15fps, 1CH 5MP@30fps, 1CH 4MP@ 30fps, 2CH 3MP@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps
  • Decode Capability: 4CH 1080P@20fps
  • Remote Sync Playback: YES
  • Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection
  • Playback Functions: Play, Pause, Stop, Fast Play, Digital Zoom


  • Interface: 1 x RJ45 10M/100M Adaptive Ethernet Interface
  • Incoming Bandwidth: 28MB
  • Onvif Version: Support ONVIF 2.4
  • Web Browser: IE-8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
  • CMS Software: Support Windows 7/ Windows 8/ Windows 10
  • Cloud Support (P2P): Yes
  • Smart Phone: iPhone, iPad, Android, Android Pad
  • WIFI: Support, WIFI Range: No obstacles 300m Max.
  • Interface Type: 1 SATA Interface(2.5inch 7mm depth)
  • Capacity: Up to 2TB capacity
  • USB Interface: 1 USB 2.0 Interfaces
  • Dimension(WxDxH): 287x142x252(mm)
More Information
ConditionBrand New
CCTV Product TypeKit
Max Recorder Channel4 Channel
Power SourceDC
Max HDD Capacity2TB
Night Vision30M
Recording Resolution5MP
System TypeIP
Cameras Included4
Lens TypeFixed
Focus ControlFixed
Shape TypeBullet
Face RecognitionNo
