Zxtech 1080p Body Temperature Recognition Camera

Zxtech AI Face Recognition and Body Temperature Measurement Access Control is a complete solution that integrates AI face recognition, body temperature measurement, mask recognition, access control and attendance capabilities. The site undertakes efficient temperature detection, identification and traffic management, effectively reducing the pressure on epidemic prevention and control and also human resource costs.

Product Overview

Zxtech AI Face Recognition camera and Body Temperature Measurement Access Control is a complete solution that integrates AI face recognition, body temperature measurement, mask recognition, access control and attendance capabilities. The site undertakes efficient temperature detection, identification and traffic management, effectively reducing the pressure on epidemic prevention and control and also human resource costs.

Protect your staff, students or visitors by doing routine monitoring for signs of fever such as temperature. Prompt individuals to self isolate or seek medical advice. Easy to use, simply turn it on. Quick and contactless. Audio alerts with high accuracy. This is a Plug and Play Face Recognition camera with a built-in thermal detection. Secure and modern design. Could be fixed to reception desks or counters.
With this device, you can avoid direct contact with people and slow the spread of the virus.
This unit can be ideal equipment to keep screening safely and efficiently of those who may potentially be infected.

During the epidemic, entrances and exits in public places basically use manual close-inquiries, manual body temperature measurement, manual registration, and personal mobile phone declarations as method top prevent and control the epidemic. This management method requires a larger number of staffs plus, staffs' self-protection standards are not uniform, which is easy to cause cross-infection. In addition, the information of the tested personnel is not comprehensive and in the event of a new epidemic, there is no good traceability mechanism.

Multi-point, multiple temperature collection, correction algorithm and other technologies are used to measure the body temperature in real-time.

Face Recognition Camera and Body Temperature Measurement Access Control can be used in residential communities, enterprises and institutions, shopping malls, supermarkets, service industry places, public transport, entrances and many other scenarios.

This unit is a high-performance, high-precision infrared thermal image AI face recognition camera, with AI functions such as fast body temperature screening, face capture, face recognition. Once it's turned on, it will be easy to be used.

This solution comes with Sony Starvis High-Performance Sensor and Full HD 1080p quality. The face recognition camera has clear and sharp images for safety, security, retail and law enforcement.

For those wanting a quick and easy solution without the hassle of setting up this face recognition camera and temperature measurement access control will be a perfect choice. It can be applied for communities, business buildings, schools, hotels, scenic spots, transportation hubs and other public service places. Thermal technology has been applied widely in temperature screening scenarios as it offers more flexibility and efficiency in a preliminary screening of elevated skin surface temperatures.

Features

• Body Temperature Monitoring
• Intelligent Recognition
• Alarm Push Notification - for abnormal temperature, no mask, stranger or blacklisted person
• Voice Broadcast Capability

What's in the Box?

• 1x Body Temperature Device
• 1x Wall mounted bracket
• 1x Power Supply
• 1x User Manual
• Screws

Tech Specs

Video

• Operation System: Embedded LINUX
• Image Sensor: 1/2.8 Hisilicon Hi3516CV500 CPU and Sony IMX327 Starvis Sensor
• Compression: H.264/H.265
• System: PAL 50HZ/NTSC 60HZ
• Resolution: 1920*1080
• LCD Size: 7-inch LCD Display
• Video Bitstream: 128Kbps-12288Kbps (Default Variable Code Rate)
• SNR: SNR ≥69dB
• Minimum Illumination: Day Mode 1Lux, Night Mode 0.01Lux
• D/N Mode: Automatic (Passive Mode)/Day Mode/Night Mode/Automatic Mode/Timing
• (AWB)/(BLC)/(AGC)/WDR: AUTO
• (AES): AUTO/ 1/50(1/60)-1/100,000sec
• Video Output: Easytool / EasyVMS / APP/ 7-inch LCD Display
• Motion Detection: Support
• Screenshot: Support

Function

• Body Temperature Test: Support (0.3-1.2M Distance, Error±0.3°C)
• Temperature Detection Sensor: Heimann Brand from Germany
• Mask Recognition: Support
• Access Control: Support

Audio

• Voice Broadcast Language: Japanese, Korean, Italian, Russian, Spanish, English, Portuguese, Chinese
• Coding Standards: G.711U
• Audio Input: Passive MIC /Speaker
• Audio Output: External 8Ω/MAX 1.5W Speaker, Built-in Speaker Support Voice Broadcast after successful recognition

Recording Management

• Recording mode: Manual Recording, Alarming Recording, Timing Recording
• Recording Storage: TF Card (Full Functional PCB )/PC/NVR

Alarming

• Alarming Input/Output: Support Weigen Protocol
• Alarming Trigger: Motion Detection Alarming, Speaker Alarming, Alarm Recording, Capture Picture, Send Email

Network

• Network Interface: RJ45 10M/100M Network Adaptation
• Wifi Module/ Protocol: M8188 (External 2.4G Antenna)/Support 802.11 b/g/n (Full Functional PCB)
• Network Protocol: HTTP, TCP/IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search (Support P6S IP Camera, DVR, NVR and etc.)

Others

• Operate Language: Japanese, Korean, Italian, Russian, Spanish, English, Portuguese, Chinese
• TF card Storage: Max Support 128GB (In common use FAT32 Format) Full Function PCB
• Working Voltage: Standard DC-12V (Wide Voltage 10-16V)
• Working Current: 160mA ±10mA
• Working Environment: -20°C --- +65°C
• Reset key: Support

Size

• PCB (mm): 85*60
• Sersor PCB (mm): 66*27
